CONCEPTUAL DESIGN, MODELLING AND SIMULATION OF A NEW UAV MULTICOPTER

Authors

  • Iulia-Theodora MARTINESCU University POLITEHNICA of Bucharest
  • Daniel DOBRE University POLITEHNICA of Bucharest

Keywords:

conceptual design, modular construction, requirements list, drone configuration, 3D modelling, quadcopter, hexacopter

Abstract

The paper aims to present the design of new models of modular multicopter UAV, where shape and performance are adapted to the current requirements of the profile market, the needs of users, and have a different aesthetic from what currently exists, which ensures good performance at a competitive price. The drone is designed to meet performance requirements such as planned flight duration (hover), system efficiency, maximum load, and maximum flight distance. Flying autonomy increases with drone configuration: a larger number of modules require more motors that allow a higher travel speed, and therefore a greater distance travelled by the drone. The 3D modelling of the drone was obtained using Autodesk Fusion 360 program for three configurations: tricopter, quadcopter and hexacopter.

Downloads

Download data is not yet available.

References

Recreational use of drones, “UAV Systems” (2022), available at: https://uavsystemsinternational.com/blogs/drone-guides/recreational-use-of-drones. Accessed: 2022-03-20.

Dobre, D. (2017). Dezvoltare de produs-Baze teoretice si studii de caz, Editura Bren, ISBN 978-606-610-117-2, Bucuresti.

Ulrich, K., Eppinger, S. (2008). Product Design and Development, McGraw-Hill, ISBN-10:0-39-044050-7

„DroneOmega” (2022). Available at: https://www.droneomega.com/drone-motor-essentials/. Accessed on: 2022-03-19.

“Arkema” (2022). Available at: https://hpp.arkema.com/en/markets-and-applications/ 3d-printing/powder-bed-fusion/#pa12. Accessed on: 2022-03-21.

„NeuMotors” 2021. Available at: https://neumotors.com/motors/neumotors-4600-series-bldc-motors-500-to-2000-watt-bldc-multicopter-motors/. Accessed on: 2022-03-16.

“Formlabs” (2021), available at: https://formlabs.com/blog/what-is-selective-laser-sintering/. Accessed on: 2022-03-23.

Downloads

Published

2022-07-01

Issue

Vol. 17 No. 1 (2022): Issue 1

Section

Research Papers

License

Copyright (c) 2022 Journal of Industrial Design and Engineering Graphics

Creative Commons License

This work is licensed under a Creative Commons Attribution-NonCommercial 4.0 International License.
